Cement Grinding Station
Get 2024 Latest Price List Online Production Line

Cement Grinding Station

  • ≤15 mmFeeding Size

  • 25-195 t/hProduction Capacity

  • ≈325 meshOutput Size

Processing Materials: Cement Clinker, Limestone, Gypsum, Fly Ash, and blending Materials.

Introduction of Cement Grinding Station

It's the final unit where cement clinker is to be mixed with some materials, like limestone, and then they will be ground by cement ball mill for the finished product-cement, an independent line distinguished with a cement production line. Among which also includes cement grinding, cement packing, and bulk production process, as well raw materials preparation and homogenization, as well as its main purpose is to grind the cement clinker (and gelling agent, performance regulating materials, etc.) to the appropriate particle size (expressed in fineness, specific surface area, etc.), and the grinding materials are sent to the high-efficiency powder concentrator for sorting by the bucket elevator. The coarse powder regrinding continues to grind, and the finished cement is collected by the air box pulse bag filter and then sent to the finished cement warehouse for storage by the air conveying chute and bucket elevator. Finally, the cement powder is bagged by pakaging machines, and then is sent to finished-part storage under the help of conveying stystem.

ZDZG-Cement Grinding Station

Application:Mainly used in building area

Hot Sale Capacity:50t/h100t/h120t/h

Popular Countries:Mainly from developing countries, like Africa, South-East Asia, Central Asia, Middle East

Main Equipment

Get Quotation

Get Factory Price

Due to its reliable performance and competitive price, our Cement Grinding Station has been exported to over 90 countries, such as USA, Pakistan, Egypt, Indonesia, Malaysia, Ethiopia, Nigeria, South Africa, etc.

About Cement Grinding Station price, we provide 100% factory price and maximum discount for you. If you are new in this industry, we will provide professional suggestions and solutions for you.

Advantages of cement grinding station

On the basis of decades of years production experience and advanced technology, we take every effort to guarantee the processing efficiency, provide better grinding machine for you and meeting your different needs.

Technical Data

Product specification
Milling form Transmission form Gear box Motor power
Production capacity
Total weight
Model Speed reduction ratio
Φ1.83×7 Open flow Brim ZD60 4.5 245 6.5-8 43.8
Φ2.2×7.5 Open flow Brim ZD70 5 380 8-10 64.8
Φ2.2×11 Open flow Brim D110 35.5 630 12-13 104.6
Φ2.2×13 Open flow Brim D110 35.5 630 16-18 114
Φ2.4×13 Open flow Brim D110 35.5 800 20-23 130.6
Φ2.6×13 Open flow Brim MFY100 19.5 1000 28-32 158
Φ3×9 Circle flow Brim D125 41.2 1000 28-36.5 167
Φ3×11 Circle flow Brim D140 42.8 1250 36-47 180
Φ3.2×13 Open flow Brim D140 36.5 1600 45-50 225
Φ3.5×13 Circle flow Brim JDX1000 5.84 2000 60-65 275
Φ3.8×13 Open flow Central shaft MFY250 16.5 2500 60-62 320
Φ4.2×13 Open flow Central shaft JQS3550 15.6 3530 85-87 380
Φ4.6×14 Circle flow Central shaft JSI160-C 14.6 4200 120-135 485
